- Evaluate the iMX RT1166 uCOM board
- On-board 1XK Wi-Fi/BT module
- 4.3 inch LCD and MIPI-to-HDMI bridge included
The iMX RT1166 Developer's Kit lets you get up-and-running quickly with the iMX RT1166 uCOM board. All relevant interfaces are available for evaluation and prototyping.
What is included when buying a kit?
- iMX RT1166 uCOM board
- uCOM Carrier board
- 4.3 inch 480x272px LCD with capacitive touch panel
- MIPI-to-HDMI bridge adapter
- 100Mbps Ethernet adapter
- 12V power supply
- Micro-B to A USB cable
- MCU-Link debug adapter
The uCOM Carrier board is a reference design for custom carrier boards using Embedded Artists’ uCOM boards.
Many RF solutions
The iMX RT1166 has an on-board 1XK Wi-Fi/BT module and there are more options to makes it simple to add RF solutions via the M.2 (B-key) and Mikrobus interfaces.
Do you want to know more?
| Connectors and interfaces | |
|---|---|
| DF40C 100/40-pos connectors for uCOM boards | |
| M.2 E-key connector (with SDIO, PCIe and USB interfaces connected) - for Wi-Fi/BT M.2 modules | |
| M.2 B-key connector (with PCIe, USB and SIM card holder interfaces connected) | |
| 1000/100/10 Mbps Ethernet RJ45 connector | |
| USB OTG interface | |
| USB Host interface | |
| uSD memory card connector | |
| Dual UART-to-USB FTDI bridge for console connections | |
| Display interface (MIPI-DSI), dual connectors | |
| Display interface (parallel RGB) with backlight control. Note: Feature not accessible with standard mounting option for the iMX RT1176 uCOM board. | |
| Camera interface (MIPI-CSI), dual connectors | |
| Debug interface with 2x5 pos 50 mil pitch Cortex debug connector | |
| Mikrobus interface connector for Click boards™ | |
| Expansion connectors for accessing uCOM board signals | |
| Power | |
|---|---|
| 12V (+-30%) supply voltage, with reverse polarity protection | |
| External VBAT power input (for uCOM RTC) | |
| Current measurement possibilities in supply voltages | |
| 5V/5A DC/DC supply to uCOM | |
| Dimensions | |
|---|---|
| 152 x 152 mm | |
| Five 4.3mm holes for mounting and grounding | |
| Other | |
|---|---|
| 2-port USB Hub | |
| On/Off, Reset, ISP Enable, Wakeup and user pushbuttons | |
| RGB-LED, LEDs, I2C-GPIOs and I2C-PWMs | |
| Pads for mounting QSPI flash memories | |
| Adapter for second 100/10 Mbps Ethernet PHY | |
| Adapter for MIPI-DSI to HDMI. Note that driver is not yet available. | |
| Product Classification | |
|---|---|
| Evaluation board | |
Note: Specifications for the uCOM board is available on the iMX RT1176 uCOM board page.
